l Parameters Detected: -by Microscopy: RBC, WBC, Fat Globule, Crystal, Parasitic Ova and other feces formed elements. Sub-classifications are also available with manual on-screen verification. -by Rapid Test Cards: FOB, transferrin, Rotavirus, Adenovirus, Coxsackie Virus, Helicobacter pylori, etc. |
|
l Automated Morphological Microscopy and Immunochemical Method |
|
? High Positive Detection Rate ü Unique designed and patented sample preparation cupguarantees more efficient collection of pathological elements, especially parasite ova, from feces sample. ü Intelligent adjustment on field of vision and automatic multi-layer focusing system captures images layer by layer and extracts parameters to avoid un-detection of pathological elements.
? High Degree of Intelligence ü Flexible options of rapid test kits ü Automatic identification of positive and negative results of rapid test kits. ü Cuvettes lining-up system ensures high comprehensive throughput. ü Suspicious elements warning system makes self-learning function possible. ü Segmentation verification system reduces workload of lab staff.
? High Reliability and User Friendliness ü Disposable high-precision cuvette eliminates risk of tubing system blocking and carryover caused by incomplete cleaning. ü Touch screen brings easy operation. ü Report displays both images and results. |
l Measurement Technology:
l Automated Morphological Microscopy and Immunochemical Method
l Parameters Detected:
-by Microscopy: RBC, WBC, Fat Globule, Crystal, Parasitic Ova and other feces formed elements. Sub-classifications are also available with manual on-screen verification.
-by Rapid Test Cards: FOB, transferrin, Rotavirus, Adenovirus, Coxsackie Virus, Helicobacter pylori, etc.
l Throughput: Up to 60 tests / hour
l Recovery Ratio of Formed Elements: ≥80%
l Reproducibility (CV): ≤20% at concentration level of 20-200 cells/μl; ≤12% at concentration level of 500-1000 cells/μl; ≤8% at concentration level of 5000 cells/μl
l Carryover Ratio of Formed Elements: ≤1 cell/μl at concentration level of 4600-5400 cells/μl; ≤2 cells/μl at concentration level of 9200-10800 cells/μl
l Loading Capacity of Cuvettes: 50 pieces
l Memory: Min. 200,000 results, including all images captured
l Built-in Computer: Yes
l Barcode Reader: External
l Printer: External and Laser
l Interfaces: Bidirectional with LIS/HIS
l Power: AC 100V-240V, 50-60Hz, 200VA
l Dimensions: 520mm*440mm*552mm
l Weight: 40kg
l Consumables
Product Name Specifications Art. No.
Feces Sample Cup 200pcs/box 10116
Cuvette 200pcs/box 10215
Fecal Occult Blood Rapid Test Kit (Colloidal Gold) 100pcs/box 40045
Fecal Occult Blood Rapid Test Kit (Duplex) 100pcs/box 40342
Transferrin Rapid Test Kit (Colloidal Gold) 100pcs/box 40144
Fecal Occult Blood and Transferrin Rapid Test Kit (Colloidal Gold) 100pcs/box 40243
